| Model number | Gridlock torqueN.m) | Number of poles | Locked-rotor currentA) | Allowable gridlock time (min) |
| YLJ63-4-0.5 | 0.5 | 4 | 0.3 | 30 |
| YLJ63-4-1.0 | 1 | 4 | 0.5 | |
| YLJ63-6-0.5 | 0.5 | 6 | 0.3 | |
| YLJ63-6-1.0 | 1 | 6 | 0.5 | |
| YLJ71-4-1.5 | 1.5 | 4 | 0.7 | |
| YLJ71-4-2.0 | 2 | 4 | 0.8 | |
| YLJ71-6-1.5 | 1.5 | 6 | 0.7 | |
| YLJ71-6-2.0 | 2 | 6 | 0.8 | |
| YLJ80-4-2.0 | 2 | 4 | 0.8 | |
| YLJ80-4-2.5 | 2.5 | 4 | 1 | |
| YLJ80-6-2.0 | 2 | 6 | 0.8 | |
| YLJ80-6-2.5 | 2.5 | 6 | 1 | |
| YLJ90-4-3.0 | 3 | 4 | 1 | 20 |
| YLJ90-4-3.5 | 3.5 | 4 | 1.4 | |
| YLJ90-4-4.0 | 4 | 4 | 1.5 | |
| YLJ90-4-4.5 | 4.5 | 4 | 1.7 | |
| YLJ90-4-5.0 | 5 | 4 | 1.8 | |
| YLJ90-6-3.0 | 3 | 6 | 1 | |
| YLJ90-6-3.5 | 3.5 | 6 | 1.4 | |
| YLJ90-6-4.0 | 4 | 6 | 1.5 | |
| YLJ90-6-4.5 | 4.5 | 6 | 1.7 | |
| YLJ90-6-5.0 | 5 | 6 | 1.8 | |
| YLJ90-8-3.0 | 3 | 8 | 1 | |
| YLJ90-8-4.0 | 4 | 8 | 1.5 | |
| YLJ90-8-5.0 | 5 | 8 | 1.8 | |
| YLJ100-4-8.0 | 8 | 4 | 3 | 10 |
| YLJ100-4-10.0 | 10 | 4 | 3.5 | |
| YLJ100-6-8.0 | 8 | 6 | 3 | |
| YLJ100-6-10.0 | 10 | 6 | 3.5 | |
| YLJ100-8-8.0 | 8 | 8 | 3 | |
| YLJ100-8-10.0 | 10 | 8 | 3.5 |
There are many types of single-phase motors, which can be divided into two categories according to different starting methods. One is the covered pole motor, which can be divided into two types: the salient pole cover pole and the hidden pole cover pole resistance phase splitting type; The other type is the split-phase motor, which can be divided into capacitive split-phase and inductive split-phase.
