In order to ensure the stable operation of the equipment, the installation of wiring is an important work. Before the torque motor wiring, we should understand the wiring circuit diagram in the design drawing and connect the wiring according to the mark in the junction box. So what should we pay attention to when wiring the torque motor? Here is a simple understanding with Senli Motor Xiaobian.

       Before we carry out wiring work, due to the strict inspection of the insulation of the motor, the torque motor used must meet the requirements of the specification, and the insulation resistance is greater than0.5Ω; If the field winding and the armature winding are reversed indirectly, the field winding may be electrified, and the field winding is not electrified and loses magnetism, so the field winding load is light and the rotor is easy to burn out. The external wires of the armature winding and the field winding cannot be misconnected with each other or indirectly.

       Torque motor manufacturersReminder: During operation, we should check whether the rotation direction of the torque motor meets the requirements; When the AC torque motor is reversed, the two torque motors can be randomly exchanged. In reverse, the two armature voltage connections can be exchanged and the two excitation voltage connections can be changed. The running sound meets the requirements, that is, abnormal sounds such as frictionless sound, hissing sound, and jammed sound, or should be stopped for inspection.
